Zinc Coated Plated Bundy Tube / Pipe Welding For Refrigerator Parts
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| High Light: | stainless steel pipe,refrigeration copper tube |
||
|---|---|---|---|
Zinc Coated Plated Bundy Tube / Pipe Welding For Refrigerator Parts
Product Details
| Type: |
Refrigerator Parts
|
Place of Origin: |
CHANGZHOU China (Mainland)
|
Brand Name: |
WUSHUN
|
| Model Number: |
Bundy Tube Welding,Zinc Coated Plated Bundy Tube Welding
|
Condition: |
New
|
Zinc Coated bundy tube: |
plated steel tubes
|
| Bundy Tube Welding: |
Zinc Coated Plated Bundy Tube Welding
|
TK: |
0.7mm
|
WT: |
0.5-0.7MM
|
| OD: |
4mm,4.2mm,4.76mm 6mm, 6.35mm.7.94mm,8mm
|
Materials: |
materials can be altered according to customers' requirements
|
Size: |
4.7*0.7mm, 6.35*0.7mm
|
| Plating: |
Copper, White&Yellow Zinc, Olive Green
|
Packaging & Delivery
| Packaging Detail: | wooden boxes,iron pallets,iron boxes etc,or we can pack it according to your request |
| Delivery Detail: | 10-15 working days after received your payment |
Specifications
Zinc Coated bundy tube,zinc plated steel tubes,Bundy Tube Welding,Zinc Coated Plated Bundy Tube Welding
Zinc Coated Plated Bundy Tube Welding
we can supply many kinds of Zinc Coated bundy tube,zinc plated steel tubes,Bundy Tube Welding,Zinc Coated Plated Bundy Tube Welding
PRODUCT DETAILS
color bundy tube /single wall bundy tube/Coating bundy tube
Size; 4.76,6.35,7.94,8mm etc
TK :0.7mm
Specifications:
1. Main use: widely used in evaporators, refrigerators, automobiles and heaters
2. Features: high intensity, good plasticity, and small resistance
3. Standard:GB/T24187-2009
4. Materials: materials can be altered according to customers' requirements
5. Size: 4.7*0.7mm, 6.35*0.7mm,
6. Type: Zinc coating outer side, Cu coating outer side, Cu coating both sides
7. Packing: packed with iron pallet
bundy tube /brake tube/ Coating bundy tube / color bundy tube / single wall bundy tube
Plating:Copper, White&Yellow Zinc, Olive Green
Size:4.76, 6.35, 8*0.7 mm,etc.
ISO9001&ISO14001
Plating:Yellow Zinc,White Zinc,Copper and PVE. Package:in coils/cut-to-length Application:Hydraulic brake line
tubing, brake
tubing, brake pipes, fuel lines, transmission oil cooler lines, air conditioning tube, power steering, condenser,
compressor,
evaporator etc.
Standard GB/T24187-2009
OD:4mm,4.76mm 6mm 6.35mm.7.94mm,8mm
WT:0.5-0.71MM
ADVANTAGES
we also can according to your drawing and samples to do it.
our price are very competitive in the market.
Specifications:
|
specification |
dimensional tolerance |
Mechanical properties |
|||
|
Diameter tolerance |
Wall thickness tolerance |
tensile strength |
yield strength |
elongation |
|
|
high frequency weld steel tube 6.35*0.7mm |
±0.08 |
±0.08 |
≥290Mpa |
≥180Mpa |
≥25% |
Competitive Advantage:
welding line can be invisible ,welding performance good ,including single wall and double wall , welding longitudinally and copper welding .Size is complete ,quality according country standard ,best quality and competitve price .
