ASME SB-163 nickel - copper alloy Steel Pipe 6mm ~ 219mm OD , bright and smooth surface
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| High Light: | hot rolled Steel Pipe,oval Steel Pipe |
||
|---|---|---|---|
ASME SB-163 nickel - copper alloy Steel Pipe 6mm ~ 219mm OD , bright and smooth surface
Quick Detail:
| Place of Origin: |
China (Mainland)
|
Type: |
Nickel Pipe
|
Application: |
powerful factory ,Sea-water exchanger and evaporator
|
| Grade: |
nickel-copper tube
|
Ni (Min): |
63
|
Powder Or Not: |
Not Powder
|
| Ultimate Strength (≥ MPa): |
480
|
Elongation (≥ %): |
35
|
Model Number: |
Monel 400
|
| Brand Name: |
FM
|
Dimensions: |
6mm~219mm(OD)*0.5mm~18mm(WT)
|
Material: |
nickel-copper alloy
|
| Standard: |
ASTM
|
name: |
monel 400 pipe
|
color: |
metal nature
|
| certificate: |
ISO 9001:2008
|
surface: |
bright and smooth
|
sizes: |
as your wish
|
Applications:
powerful factory ,Sea-water exchanger and evaporator
Specifications:
Monel 400 seamless tube and welded tube is our representative product. We can produce the smaller OD tube.
Packing detail: export wooden case
Delivery : within 15-50 days or according to the customers' requirment
Description:
Standards: ASME SB-165; ASME SB-163; ASME SB-730; ASME SB-751; ASME SB-775;ASME SB-829,AMS 4574
We sell large quantities of Monel 400 welded tube and seamless tube to Korea, Canada, Spain, India customers.
| Chemical analysis of Alloy 400 | |||||
| C | Mn | S | Si | Ni | Cu |
| 0 .3 max | 2.0 max | 0.024 max | 0.5 max | 63.0 min | 28 - 34 |
| Specifications of Monel 400 | |||
| Sheet/Plate | Round Bar | Pipe | Tube |
| ASME SB-127 AMS 4544 |
ASME SB-164 AMS 4675 |
ASME SB-725 ASME SB-751 |
ASME SB-165 ASME SB-775 ASME SB-829 AMS 4574 |
Competitive Advantage:
1. We offer you our best price with good quality of the materials.
2. We will deliver the materials strictly according to the the delivery date noted on the contract.
3. We also always have the huge ready stock for sell.
4. We have advanced NDT equipments for the tests such as Eddy Current test, Ultrasonic test, Hydraulic test and so on.
5. We have complete after-sale service to deal with the problems in time.
