10CrMo910 12Cr1MoV Seamless Alloy Steel Boiler Pipe 10mm - 810mm * 2mm - 65mm
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| High Light: | hot rolled Steel Pipe,oval Steel Pipe |
||
|---|---|---|---|
10CrMo910 12Cr1MoV Seamless Alloy Steel Boiler Pipe 10mm - 810mm * 2mm - 65mm
Quick Detail:
| Thickness: |
2 - 65 mm
|
Section Shape: |
Round
|
Outer Diameter: |
10 - 810 mm
|
| Place of Origin: |
China
|
Secondary Or Not: |
Non-secondary
|
Application: |
Boiler Pipe
|
| Technique: |
Cold Drawn
|
Certification: |
BSI
|
Surface Treatment: |
anti rust
|
| Alloy Or Not: |
Is Alloy
|
Grade: |
10MoWVNb,16Mn,10CrMo910,
12Cr1MoV,12Cr2Mo,12CrMo195,
15CrMo,35CrMo4,1Cr13Mn9Ni1N,
Cr17Ni8,09Mn2V,15MnV,1
5Mo3,16Mo,16mo3,Cr-Mo alloy,
CrNi alloy,Mn-V alloy,Mo
|
Standard: |
ANSI A210-1996,ANSI A213-2001,ASME
|
Applications:
Boiler Pipe
Specifications:
1. seamless alloy pipe
2. Size:10-810mm*2-65mm
3. a213 t11-t92
4. Origin:China&Japan
5. ISO,SGS, BV LR Approved
6. Packing detail: BUNDLESS, LOOSE IN CONTAINER, WORTH SEA CREATES AND
OTHER EXPORTING STANDARD PACKING
7. within 5-10 days or according to the customers' requirment
Description:
| Standard | Steel Grade | Tensile Strength(MPa) | Yield Strength(MPa) | Elongation(%) | Hardness |
| GB3087 | 10 | 335~475 | ≥195 | ≥24 | / |
| 20 | 410~550 | ≥245 | ≥20 | ||
| GB5310 | 20G | 410~550 | ≥245 | ≥24 | / |
| 20MnG | ≥415 | ≥240 | ≥22 | ||
| 25MnG | ≥485 | ≥275 | ≥20 | ||
| 15CrMoG | 440~640 | ≥235 | ≥21 | ||
| 12Cr2MoG | 450~600 | ≥280 | ≥20 | ||
| 12Cr1MoVG | 470~640 | ≥255 | ≥21 | ||
| 12Cr2MoWVTiB | 540~735 | ≥345 | ≥18 | ||
| 10Cr9Mo1VNb | ≥585 | ≥415 | ≥20 | ||
| ASME SA210 | SA210A-1 | ≥415 | ≥255 | ≥30 | ≤143HB |
| SA210C | ≥485 | ≥275 | ≥30 | ≤179HB | |
| ASME SA213 | SA213 T11 | ≥415 | ≥205 | ≥30 | ≤163HB |
| SA213 T12 | ≥415 | ≥220 | ≥30 | ≤163HB | |
| SA213 T22 | ≥415 | ≥205 | ≥30 | ≤163HB | |
| SA213 T23 | ≥510 | ≥400 | ≥20 | ≤220HB | |
| SA213 T91 | ≥585 | ≥415 | ≥20 | ≤250HB | |
| SA213 T92 | ≥620 | ≥440 | ≥20 | ≤250HB | |
| DIN17175 | ST45.8/Ⅲ | 410~530 | ≥255 | ≥21 | / |
| 15Mo3 | 450~600 | ≥270 | ≥22 | ||
| 13CrMo44 | 440~590 | ≥290 | ≥22 | ||
| 10CrMo910 | 480~630 | ≥280 | ≥20 |
Competitive Advantage:
1. We offer you our best price with good quality of the materials.
2. We will deliver the materials strictly according to the the delivery date noted on the contract.
3. We also always have the huge ready stock for sell.
4. We have advanced NDT equipments for the tests such as Eddy Current test, Ultrasonic test,
Hydraulic test and so on.
5. We have complete after-sale service to deal with the problems in time.
