Large Diameter Alloy Steel Pipe
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| High Light: | hot rolled Steel Pipe,alloy steel seamless pipes |
||
|---|---|---|---|
Large Diameter Alloy Steel Pipe
Quick Detail:
| Place of Origin: |
China
|
Type: |
Nickel Pipe
|
Application: |
petrochemical, aerospace, shipbuilding, energy, military industry
|
| Grade: |
nickel base alloy
|
Ni (Min): |
60%
|
Resistance (μΩ.m): |
N/A
|
| Powder Or Not: |
Not Powder
|
Ultimate Strength (≥ MPa): |
700
|
Elongation (≥ %): |
35
|
| Model Number: |
DN6-DN100
|
Brand Name: |
steelwell
|
Grade No.: |
alloy C-276
|
| other name: |
UNS N10276
|
other name1: |
W.Nr. 2.4819
|
density: |
8.9g/cm3
|
| finish: |
black or bright
|
origin: |
China
|
standard: |
ASTM B 626
|
| delivery time: |
5-60 days
|
package: |
export wooden case
|
delivery name: |
alloy C-276
|
Applications:
petrochemical, aerospace, shipbuilding, energy, military industry
Specifications:
alloy C-276 (UNS N10276/W.Nr. 2.4819) is known for its corrosion resistance in a wide range of
aggressive media.
Competitive price and stable capacity
Packing detail: export wooden case
Delivery : within 15-50 days or according to the customers' requirment
Description:
Chemical composition:
Nickel.............................................................................Balance
Molybdenum ...............................................................15.0-17.0
Chromium....................................................................14.5-16.5
Iron ..................................................................................4.0-7.0
Tungsten..........................................................................3.0-4.5
Cobalt ...........................................................................2.5 max.
Manganese ...................................................................1.0 max.
Carbon........................................................................0.01 max.
Vanadium....................................................................0.35 max.
Phosphorus ................................................................0.04 max.
Sulfur ..........................................................................0.03 max.
Silicon .........................................................................0.08 max
Characteristic as below:
Alloy c-276 is a nickel-chromium-molybdenum alloy containing tungsten and extremely low carbon and
silicon contents.
Alloy c-276 is characterised by:
1.excellent resistance to a wide range of corrosive media,
under oxidizing and reducing conditions
2.excellent resistance to pitting, crevice corrosion,
Corrosion resistance:
Alloy c-276 can be used in many chemical processes with oxidizing and with reducing media.Its
corrosion resistance in lightly aerated, technical grade sulphuric acid is shown in Fig. 2. Except
for areas where acorrosion rate of > 0.5 mm/a is indicated the use of Alloy c-276 is considered suitable.
The high molybdenum and chromium contents render the
alloy resistant to chloride ion attack. The tungsten content further increases this resistance.
Alloy c-276 is one of the few materials that is resistant to moist chlorine gas, hypochlorite and chlorine
dioxide solutions. The alloy exhibits excellent resistance to concentrated solutions of oxidizing
salts(such as iron (III) chloride and copper chloride)
Application range and field:
1.Pulp and paper industry, e.g. for digestion and bleaching vessels
2.Scrubbers and special reheaters as well as wet-operating
3.fans for combustion and flue gas desulphurisation systems
4.Equipment and components for sour-gas service
5.Reactors for acetic acid production
6.Sulphuric acid coolers
7.Methylene diphenyl isocyanate (MDI)
8.Manufacture and processing of technically impure phosphoric acid
9.Combustion-resistant alloy for high pressure oxygen
There are a lot of style for reference
Competitive Advantage:
1. We offer you our best price with good quality of the materials.
2. We will deliver the materials strictly according to the the delivery date noted on the contract.
3. We also always have the huge ready stock for sell.
4. We have advanced NDT equipments for the tests such as Eddy Current test, Ultrasonic test,
Hydraulic test and so on.
5. We have complete after-sale service to deal with the problems in time.
