2B Finished Stainless Steel Round Tube , Schedule 10 / Schedule 5 SS Pipe

2B Finished Stainless Steel Round Tube , Schedule 10 / Schedule 5 SS Pipe
2B Finished Stainless Steel Round Tube , Schedule 10 / Schedule 5 SS Pipe

Large Image :  2B Finished Stainless Steel Round Tube , Schedule 10 / Schedule 5 SS Pipe Get Best Price

Product Details:
Place of Origin: China
Brand Name: Cosco Steel
Certification: ISO,SGS,CQC,etc.
Payment & Shipping Terms:
Minimum Order Quantity: 500Kgs/ one size
Price: Negotiation
Packaging Details: Plastic bag in bundle,Wooden box,etc.
Delivery Time: 10-15 days
Payment Terms: L/C,T/T,Paypal
Supply Ability: 600Tons/Month
Contact Now
Detailed Product Description
Surface Finish: 2B Finish Diameter: 1/2" , 3/4" , 1" , 2" , 2-1/2" , 3" , 3-1/2" , 4" , 5" , 6" , 8" , 10" , 12 "
Wall Thickness: Sch 5S, Sch 10S Length Of Pipe: 20 Feet / 5.8 Meter Or 6 Meter
High Light:

welded steel pipes

,

welded boiler tube



2B Finished Stainless Steel Round Tube , Schedule 10 / Schedule 5 SS Pipe





Quick Detail:



Product Name

ERW Welded Stainless Steel Pipe

Surface Finish

1. 2B Finish  2. Pickled Finished  3. Annealed&Pickled

Material

304/L, 316L/Ti, 310S etc.

Outside Diameter

20mm - 2000mm

Wall Thickness

1mm,1.2mm,1.5mm,2.0mm ... 30mm.

Length

1000mm,2000mm,3000mm....12000mm

Market

USA,Canada,Japanese,European etc.





Description:

  1. Product Item No.: 0030welded-Cosco Steel
  2. Type: Round Or Oval
  3. Material: Main

  1. 4301/ SUS304/ AISI304/ S30400,

  1. 4306/ SUS304L/ AISI304L/ S30403,

  1. 4404/ SUS316L/ AISI316L/ S31603, etc.



Standard:

  GB/T12771-2008, ASTM A312, ASTM A789, JIS G3448,

  DIN EN10216-5, DIN EN10217-7, etc.

  1. Size: 1/2” to 48”
  2. Wall Thickness: Sch5s,Sch10s,Sch40S
  3. Marking: Registered logo,Heat Number,Steel Grade,Standard,Size
  4. H.S Code: 7306.4000





Applications:



This type welded tubes/pipes be used in

  1. Industrial fluid conveying pipes
  2. Mechanical structural tubes
  3. Heat ex-changer and condenser tubes
  4. Walled water tubes
  5. Larger caliber industrial welded pipes etc.



Specifications



Designation: A312/A312M-04a

Standard specifications For Seamless,Welded,And Heavily Cold Worked Austenitic

Stainless Steel Pipe



Manufacture Process

ERW Welded ( ELD ) Pipe







Quality Inspection






  1. Metallographic Analysis
  2. Physical And Chemical Analysis
  3. Specification Eccentricity Test
  4. Mechanical Test
  5. PMI Test
  6. Eddy Current Test
  7. Large-Size Ultrasonic Flaw Test
  8. Ultrasonic Flat Test
  9. Thickness Test   etc.







Mechanical Requirements

 Grade   UNS Designation   Tensile Strength   Yield Strength

                                             Min Ks i [M pa]   Min Ks i [M pa]

 TP304    S30400                        75 [515]         30 [205]

 TP304L   S30403                       70 [485]         25 [170]

 TP309S   S30908                        75 [515]         30 [205]

 TP310S   S31008                        75 [515]         30 [205]

 TP316L   S31603                        70 [485]         25 [170]

  ....          ....                .....               .....
  1. Specification No.
  2. Pipe
  3. Grade
  4. NPS
  5. Wall
  6. SMLES OR WELDED ...
  • ASTM A312
  • P
  • TP304
  • 12IN
  • 0.375 IN
  • WELDED .....
