304 316L stainless steel welded pipe , polished 400# 600# , bright surface
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Name: | Stainless Steel Pipe | Type: | Welded |
|---|---|---|---|
| Material: | 201 304 316L | Length: | 6000mm |
| Thickness: | 0.3-3.0mm | Od Size: | 10-100mm |
| High Light: | stainless steel pipe welding standards,stainless steel welded tube |
||
Quick Detail:
food grade 304 316L stainless steel welded pipe
| name | stainless steel welded pipe | size | 10-100mm |
| wall thickness | 0.3-3.0mm | length | 6000mm |
| surface | outsize polish 400# 600# | grade | 304 316L |
food grade stainless steel welded pipe is both polished in the outsize and inside, the welded line is can't be seen inside of the pipe.
Description:
|
Stainless Steel Ornamental Round Tube |
||
|
1 |
Item |
Welded Stainless Steel Ornamental Round Tube |
|
2 |
Material |
201/304/316L |
|
3 |
Outside Diameter |
9.50mm - 101mm (3/8'' - 4'') |
|
4 |
Thickness (mm) |
0.7, 0.8, 0.9, 1.0, 1.2, 1.5, 2.0mm |
|
5 |
Length |
6m (can be customized to meet customer requirement) |
|
6 |
Standard |
AISI/ASTM |
|
7 |
Finish |
polished inside and outside, 400# & 600# |
|
8 |
Packing |
Each Tube is pp sleeved/ In Standard Seaworthy Export Packing |
|
We can produce customized size and length according to customer requirement. |
||
Applications:
food grade stainless steel pipe is both side polished(inside and outside),it is widely used for foodstuff, Dairy & Beverage, personal care, Biotech, Pharmaceutical, Sanitary industrial, "High clean" industrial and so on^
Specifications
Food grade stainless steel refers to food machinery parts that come in direct contact with food, must conform to the requirements of food safety. Because food production process to use a lot of acid and alkali, and stainless steel containing chromium, unqualified stainless steel, will dissolve out of various price chromium, toxic; And required to limit the variety of metal impurity elements such as lead, cadmium content.
|
Material Grade |
304 (Ni 8%, Cr 18%), |
|||||
|
Outer Diameter |
10mm-100mm or as your requirement |
|||||
|
Thickness |
0.15mm - 30mm or as your requirement |
|||||
|
Length |
2.5m-- 8m or as customers' request |
|||||
|
|
a) Outer Diameter:+/- 0.2mm |
|||||
|
b) Thickness: +/- 0.02mm |
||||||
|
c) Length: +/- 5mm |
||||||
|
Surface |
180G, 320G, 400G Satin / Hairline |
|||||
|
|
Material |
304 |
316 |
430 |
||
|
C |
≤0.08 |
≤0.08 |
≤0.12 |
|||
|
Si |
≤1.00 |
≤1.00 |
≤1.00 |
|||
|
Mn |
≤2.00 |
≤2.00 |
≤1.00 |
|||
|
P |
≤0.045 |
≤0.045 |
≤0.040 |
|||
|
S |
≤0.030 |
≤0.030 |
≤0.030 |
|||
|
Cr |
18-20 |
16-18 |
16-18 |
|||
|
N |
8-10.5 |
10-14 |
|
|||
|
Mo |
|
2.0-3.0 |
|
|||
|
|
Material Item |
304 |
316 |
|||
|
Tensile Strength |
≥520 |
≥520 |
||||
|
Yield Strength |
≥205 |
≥205 |
||||
|
Extension |
≥35% |
≥35% |
||||
|
Hardness (HV) |
<200 |
<200 |
||||
|
Delivery time |
A. 7 days if this goods is stock goods. |
|||||
Competitive Advantage
A) Small MOQ
B) Large supply ability
C) Can accept any complex inquiry
D) Stock available
E) Strong processing and warehousing service
F) Strict quality control
G) Professional negotiation
H) Reasonable price
I) Quick and stable delivery time
J) Good after-sales service
