Q235 Q345 Greenhouse Pre Galvanized Steel Tubing , ERW Steel Structure Pipe
|
|
Product Details:
|
Detailed Product Description
| High Light: | pre galvanized steel tube,galvanised steel pipe |
||
|---|---|---|---|
Q235 Q345 Greenhouse Pre Galvanized Steel Tubing , ERW Steel Structure Pipe
Quick detail:
1. Out diameter :20-219mm
2. Thickness:0.5-2.3mm
3. Length: usually 4.5-6.5m, can up to 12m, or as client's requirements
4. Znic Coating:60-80g/m2,Max 120g/m2
5. End Treatment:Threading, Grooving, Bevelling or Plain. And we have our own processing workshop. So we can do many processings like threading, cutting, grooving, stamping, packing, bevelling, welding and so on.
6. End Protector :Plastic cap, coupling( socket), nipple, elbow, tee, flange and some other pipe fitting
Description:
- Place of Origin: Tianjin, China (Mainland)
- Secondary Or Not: Non-secondary
- Application: Structure Pipe
- Technique: ERW
- Certification: BV
- Surface Treatment: Galvanized
- Special Pipe: Thick Wall Pipe
- Alloy Or Not: Non-alloy
|
Product Name: |
BS 1387 BS EN 10297 pre galvanized steel tubing OD From 15-168MM quality of Q235, Q345, Q195, Q215 used for greenhouse, gas or water delivery pipe, construction and so on.
|
|
|
Size |
OD |
15mm-168mm |
|
Wall Thickness |
0.5mm-3mm SCH30,SCH40,STD,XS,SCH80,SCH160,XXS etc. |
|
|
Length |
1m-12m |
|
|
Steel material |
Q195,Q235.Q215,16Mn,SS400 |
|
|
Standard |
BS 1387 BS EN 10297 |
|
|
Usage |
used for greenhouse, gas or water delivery pipe, construction etc. |
|
|
Ends |
1) Plain 2) Beveled 3) Thread with Coupling or cap |
|
|
End protector |
1) Plastic pipe cap 2) Iron protector |
|
|
Surface Treatment |
1) Bared 2) Black Painted (varnish coating) 3) Galvanized 4) With Oiled 5) 3 PE, FBE, corrosion resistant coating |
|
|
Technique |
Electronic Resistance Welded (ERW ) Electronic Fusion Welded (EFW) Double Submerged Arc Welded (DSAW) |
|
|
Type |
Welded Pipe |
|
|
Welded Line Type |
Longitudinal |
|
|
Section Shape |
Round |
|
|
Inspection |
With Hydraulic Testing, Eddy Current , Infrared Test |
|
|
Package |
1) Bundle, 2) In Bulk 3) Bags 4) Clients' Requirements |
|
|
Delivery |
1) Container 2) Bulk carrier |
|
|
Port of Shipment |
Xingang Port,Tianjin, China |
|
|
Payment |
L/C T/T |
|
|
Others |
Fitting as screws and flange also can be supplied. |
|
Applications:
It is widely used in Mechanical & manufacture, Steel structure,Shipbuilding, Bridging ,Automobile, etc. And it is mainly used for greenhouse, frame, cage, construction.
Specifications:
|
Inch |
OD |
DN |
|
1/2” |
21mm |
15 |
|
3/4” |
26 mm |
20 |
|
1” |
33 mm |
25 |
|
1-1/4” |
42 mm |
32 |
|
1-1/2” |
48 mm |
40 |
|
2” |
60 mm |
50 |
|
2-1/2” |
76(73)mm |
65 |
|
3” |
89 mm |
80 |
|
4” |
114 mm |
100 |
|
5” |
140 mm |
125 |
|
6” |
165(168) mm |
150 |
|
8” |
219 mm |
200 |
|
10” |
273 mm |
250 |
|
12” |
325 mm |
300 |
|
14” |
377 mm |
350 |
|
16” |
426 mm |
400 |
Standard: BS 1387 BS EN 10297
Quality: Q195.Q235,Q215,16Mn.SS400,
Competitive Advantage:
Due to our newest technology ,We cut down much from our cost. It will cheaper much than the hot dipped galvanized steel pipe We have 5 production lines, with the annual output reaching 200,000 tons, and our products are widely sold in markets aboard, such as Australia, South America, Africa, Southeast Asia and the Middle East , with annual export sales reaching 50,000 tons.
