Heat exchanger 304 316 430 201 202 316L seamless stainless steel tube

Large Image : Heat exchanger 304 316 430 201 202 316L seamless stainless steel tube Get Best Price

Product Details:

Place of Origin:	China(Mainland)
Brand Name:	SX STEEL
Certification:	SGS,ISO,BV,CE
Model Number:	200,300,400 series

Payment & Shipping Terms:

Minimum Order Quantity:	5 tons
Price:	Negotiated
Packaging Details:	Export standard package :bundled wooden box or be required
Delivery Time:	7-15 working days
Payment Terms:	L/C T/T Western Union
Supply Ability:	1000 Ton/Tons / Week

Contact Now

Detailed Product Description

High Light:

Stainless Steel Welded Pipe

polished stainless steel pipe

Heat exchanger 304 316 430 seamless stainless steel pipe / tube OD 6mm - 219mm

Quick Detail:

Name	Stainless steel pipe	Brand Name	SX
WT	0.5mm-50mm	Feature	High quality
Grade	200,300,400 series	Certificate	SGS,ISO,BV,CE

Description:

1. Name: 201,304,316,430 seamless stainless steel pipe/tube OD 6mm-219mm for heat exchanger with high quality on sale made in china

2. Outer Diameter: 6mm-730mm (1/8"-20")the specifications can be produced according to your specific inquiry

3. Wall Thickness: 0.5mm-50mm (10S-160S)

4. Length: 13m Max

5. Grade: 201,202,304,304L, 316,316L,321,310,317L,301,430 etc

6. Standard: ASTM A312/213/269, EN10216-5, DIN17456/17458, JIS3459

7. Application: widely used in petroleum, Foodstuff, chemical industry, construction, electric power, nuclear energy, biotechnology, machinery, papermaking, shipbuilding, boiler fields etc

8. Packing: Wraps with kraft paper, steel strip bundled,wooden matting,or as per customers' requirements, seaworthy bundle wooden case if required

9. Payment: T/T and L/C at sight

10. Certificate: ISO,SGS,BV,CE

11. Delivery: Within 15 days

Applications:

1) Building materials, which including elevators, inside and outside decoration materials of buildings, windows, doors and heaters.

2) Structure tubes and drainpipe in industrial field.

3) Chemical equipments, boilers, tanks, chemical industrial furnaces, chemical equipment parts.

4) Other application: such as processing plants, anything with high hardness.

Specifications:

Name	Seamless Stainless Steel pipe
Standard	ASTM,AISI,JIS,EN,GB,DIN etc
Material Grade	201 ( Ni 0.8%), 202 (Ni 3.5%~4.5%), 301(Ni 5%) 304 (Ni 8%, Cr 18%), 316 (Ni 10%, Cr 18%), 316L (Ni10%~14%),
Outer Diameter	6mm--730mm
Thickness	0.5mm - 50.0mm
Length	6m or as customers' request
Tolerance	a) Outer Diameter: +/- 0.2mm
	b) Thickness: +/- 0.02mm
	c) Length: +/- 5mm
Surface	180G, 320G, 400G Satin / Hairline 400G, 500G, 600G or 800G Mirror finish
Application	Decoration construction, upholstery, industry instrument
Test	Squash test, extended test, water pressure test, crystal rot test, heat treatment, NDT
Mechanical Property	Material Item	201	202	304	316
	Tensile Strength	≥535	≥520	≥520	≥520
	Yield Strength	≥245	≥205	≥205	≥205
	Extension	≥30%	≥30%	≥35%	≥35%
	Hardness (HV)	<253	<253	<200	<200

Payment

Payment by T/T, 30% as advance payment and 70% balance pay before shipping.

Delivery time

A.7 days if this goods is stock goods.

B.30 days if this goods will be produced after order

Validity

Valid time is 3 days for price usually.

Chemical composition

Grade	C	Si	Mn	P	S	Ni	Cr	Mo
201	≤0.15	≤1.00	5.5-7.5	≤0.060	≤0.03	3.5-5.5	16.0-18.0
202	≤0.15	≤1.00	7.5-10.00	≤0.060	≤0.03	4.0-6.0	17.0-19.0
301	≤0.15	≤1.00	≤2.00	≤0.045	≤0.03	6.0-8.0	16.0-18.0
302	≤0.15	≤1.00	≤2.00	≤0.045	≤0.03	8.0-10.0	17.0-19.0
304	≤0.07	≤1.00	≤2.00	≤0.045	≤0.03	8.0-10.0	18.0-20.0
304L	≤0.030	≤1.00	≤2.00	≤0.045	≤0.03	9.0-13.0	18.0-20.0
310S	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	19.0-22.0	24.0-26.0
316	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	10.0-14.0	16.0-18.0	2.0-3.0
316L	≤0.03	≤1.00	≤2.00	≤0.045	≤0.03	12.0-15.0	16.0-18.0	2.0-3.0
321	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	9.0-13.0	17.0-19.0
430	≤0.12	≤0.75	≤1.00	≤0.040	≤0.03	≤0.60	16.0-18.0
430A	≤0.06	≤0.50	≤0.50	≤0.030	≤0.50	≤0.25	14.0-17.0

Competitive Advantage:

(1): High quality stainless steel pipes with reasonable price.
(2): Wide excellent experiences with after-sale service.
(3): Every process will be checked by responsible QC which insures every product's quality.
(4): Professional packing teams which keep every packing safely.
(5): Trial order can be done in one week.
(6): Samples can be provided as your requirements.

We are professional manufacturer of stainless steel products, including decorative welded stainless steel pipes,industrial welded stainless steel pipes, special-shaped welded pipes, stainless steel

sheet and etc. Main materials are: 304, 201,202,316,316L,430 and so on.

If you are interested in our products, please feel free to contact with us, we will try our best to meet your demands.
