AS 321 ASTM A240 04Gr18Ni11Ti Cold Rolled Steel Coils Slitting Edge , 0.17mm - 3.0mm Thickness
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Chemical, Transport | Edge: | Mill Edge, Slitting Edge |
|---|---|---|---|
| Grade: | ASTM A240 321, JIS SUS 321, AS 321 | Materials: | 304, 321 |
| Product Name: | Stainless Steel Coils | Standard: | JIS, ASTM, GB, DN, SUS, EN, DIN, ASTM A240, AS |
| Surface Treatment: | 2B, BA, 8K, Mirror, 2D | Technique: | Cold Rolled |
| Thickness: | 0.17mm - 3.0mm | Width: | 10.0mm - 850mm |
| High Light: | steel sheet coil,sheet metal coil |
||
AS 321 ASTM A240 04Gr18Ni11Ti Cold Rolled Steel Coils Slitting Edge , 0.17mm - 3.0mm Thickness
Descrition:
1. Material:Ferrite stainless steel, magnetic.
2. Grade:ASTM A240 321, JIS SUS 321, AS 321
3. Technology:Cold Rolled
4. Standard:AISI, ASTM, EN, GB, DIN, JIS
5. Thickness:0.17mm - 3.0mm (tolerances ±0.02mm)
6. Width:10.0mm - 850mm (tolerances ±6.00mm)
7. Coil ID:Φ500mm-600mm Coil OD Φ2100mm max.
8. Edge:Mill Edge / Slitting edge
9. Annealed:Full hardness to Deep drawing quality (DDQ)
Applications:
321 stainless steel applications
|
Surface finish |
Characteristics and application |
|
NO. 2B |
The surface brightness and flatness of no2B is better than no2D. then through a special surface treatment to improve its mechanical properties, No2B could nearly satisfy comprehensive uses. |
|
NO. 3 |
Polished with abrasive belt of git#100-#200, have better brightness with discontinuous coarse stria, used as inner and external ornaments for building, electrical appliances and kitchen utensils etc. |
|
NO. 4 |
Polished with abrasive belt of grit #150-#180, have better brightness with discontinuous coarse stria, but thinner than No3, are used as bathtub buildings inner and external ornaments electrical appliances kitchen utensils and food processing equipment etc. |
|
HL |
Polished with abrasive belt of grit #150-#320 on the NO. 4 finish and has continuous streaks, mainly used as buildings ornaments elevators, door of building, frontal plate etc. |
|
BA |
Cold rolled, bright annealed and skin-passed, the product have excellent brightness and good reflexivity like mirror, kitchen apparatus, ornament etc. |
|
8K |
The product have excellent brightness and prefer reflexivity can to be the mirror. |
Specifications:
ASTM A240/SUS 321 stainless steel Chemical composition(%):
|
C |
Si |
Mn |
S |
P |
Cr |
Ni |
|
≤0.07 |
≤1.00 |
≤2.00 |
≤0.030 |
≤0.035 |
17.00-19.00 |
8.00-11.00 |
ASTM A240/SUS 321/AS 321 stainless steel Mechanical property:
|
TYPE |
Yield Strength |
Tensile Strength(Mpa ) |
Extension(%) |
Hardness(HV) |
|
321 |
≥205 |
≥520 |
≥40 |
≤200 |
ASTM A240/SUS 321 stainless steel Grade:
|
Standard |
GB |
AISI/ASTM |
JIS |
DIN |
BS |
|
Grade |
1Cr18Ni9Ti |
321,S32100,TP321 |
SUS321 |
X10CrNiTi189 |
304S12,321920 |
Competitive Advantage:
The reason why you Choose us:
· SGS and BV Audited company .
· Industry experience over 50 years.
· Management Systems-Internal Software
· Finished Product Inventory-More Than 50000 Tons.
· Raw Material inventory -Over 80000 Mertic Tons.
· Shipment of goods -More than 50 countries worldwide.
· We have the most convenient transport and prompt delivery.
· We offer competitive price with best service .
· We have high technical production line with top quality products.
· We have win high reputation based on best quality products.
