GMC 380V Steel Sheet Cut To Length Machine Electric For Stainless Steel Coil

GMC 380V Steel Sheet Cut To Length Machine Electric For Stainless Steel Coil

Specifications

cut to length line
1. We do Care Details;
2. We do Use Qualified Material;
3. We do Use High Precision Tooling Treatment;

1.components

  1, paper collecting device 1set
  2, Coil loading car(with base) 1set
  3, Decoiler (with arm) 1set
  4, Coil guide device 1set
  5, Squeeze roller and accurate fifteen-roller leveler 1set
  6, Loop 1set
  7, Guiding device 1set
  8, Film device 1 set
  9, Sizing leveler with 5 rollers 1set
  10, Fly shear 1set
  11, Belt transporting device 1set
  12, Stacker 1set
  13, Platform 1set
  14, Stacking dolly 2sets
  15, Hydraulic, lubrication and pneumatic system 1set
  16, Electric system 1set

2.technical parameters

  2.1 Steel coil parameters
        1. Suitable material: Stainless steel coil,

        2. Yield stress: σs≤205Mpa σb≤650Mpa
        3. Coil thickness: 0.5~3mm
        4. Coil width: 500~1600mm
        5. Coil ID: Φ508/Φ610
        6. Coil OD: Φ1000~Φ1600mm m
        7. Coil weight: ≤10T

  2.2 Finished products parameters

        1. Cut to length: 500-6000mm

        2. Tolerance of length: ≤±1/3000
        3. Tolerance of catercorner:≤±1.5/3000
        4. Stack weight:3000kg,max. height 400mm
