2B BA JIS AISI ASTM 316 Stainless Steel Coil mirror finish stainless steel sheeting
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| High Light: | Cold Rolled Stainless Steel Coils,stainless steel sheet coil |
||
|---|---|---|---|
2B BA 316 Stainless Steel Coil JIS AISI ASTM mirror finish stainless steel sheeting
Quick Detail:
1. Commodity: 316 stainless steel sheet
2. Brand: JISCO, LISCO, TISCO
3. Grade: 316
4. Certification: ISO,SGS BV
5. Surface: 2B, or as requested
6. Thickness: 0.5mm-3mm
7. Width: 1000mm/1219mm/1500mm
8. Length: coil or as customer's requirement
9. Standard: JIS, AISI, ASTM, etc.
Specifications
|
Item |
316 stainless steel sheet |
|
Standard |
ASTM,AISI,SUS,JIS,EN,DIN,BS,GB |
|
Material |
201,202,304,304L,309S,310S,316,316L,316Ti,317L,321,347H, 409,409L,410,420,430 |
|
Finish(Surface) |
NO.1, NO.2D, NO.2B, BA,NO.3, NO.4,NO.240,NO.400,Hairline, NO.8,Brushed |
|
Thickness |
Form0.5mm-6mm |
|
Width |
1000mm,1219mm,1500mm,etc or we can also help cut as you require |
|
Length |
2000mm,2440mm(8feet),2500mm,3000mm,3048mm(10feet),5800mm, 6000mm ,8000mm or we can make the length as you require |
|
Application |
Stainless steel sheet applies to construction field, ships building industry, petroleum & chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchanger, machinery and hardware fields. Stainless steel sheet can be made accordingto the customers requirements. Fast delivery. Quality assured.Welcome to order more. |
|
Package Details |
Standard seaworthy package(wooden boxes package,pvc package, and other package) |
|
Delivery Time |
According to your size and quantity or as customers require |
|
Payment Term |
T/T ,L/C, Western Union |
|
Payment |
Payment by T/T, 30% as advance payment and 70% balance pay before shipping. |
Regular size
| Thickness (mm) | Width (mm) |
| 0.5 | 1000 |
| 0.5 | 1219 |
| 0.6 | 1000 |
| 0.6 | 1219 |
| 0.7 | 1000 |
| 0.7 | 1219 |
| 0.8 | 1000 |
| 0.8 | 1219 |
| 1.0 | 1000 |
| 1.0 | 1219 |
| 1.2 | 1000 |
| 1.2 | 1219 |
| 1.5 | 1000 |
| 1.5 | 1219 |
| 2.0 | 1000 |
| 2.0 | 1219 |
| 2.5 | 1000 |
| 2.5 | 1219 |
| 3.0 | 1000 |
| 3.0 | 1219 |
| 3.0 | 1500 |
|
Stainless Steel 300 Series |
||||||||||||||
|
Grade |
Chemical Composition |
Mechanical Properties |
||||||||||||
|
|
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Mo |
|
Y.S |
T.S. |
ELOG. |
HRB |
|
|
% |
% |
% |
% |
% |
% |
% |
% |
|
N/mm2 |
N/mm2 |
% |
|
||
|
304 |
≤ 0.08 |
≤ 0.75 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
8~10 |
18~20 |
|
|
≥ 205 |
≥ 520 |
≥ 40 |
≤ 90 |
|
|
301 |
≤ 0.15 |
≤ 1.00 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
6~8 |
16~18 |
|
|
≥ 205 |
≥ 515 |
≥ 40 |
≤ 95 |
|
|
316 |
≤ 0.08 |
≤ 1.00 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
10~14 |
16~18 |
2~3 |
|
≥ 205 |
≥ 515 |
≥ 40 |
≤ 90 |
|
|
316L |
≤ 0.03 |
≤ 1.00 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
12~15 |
16~18 |
2~3 |
|
≥ 170 |
≥ 480 |
≥ 40 |
≤ 95 |
|
|
The specification of type 301, 304, 316, 316L according with ASTM and JIS standard. |
||||||||||||||
advantage:
Our company located in shanghai,near Shanghai port,it is convenient to transport the cargo to the port, so it save the time,and can cut down the delivery time also can save the cost of transportation, the customer can get the benefit.
