ASTM 409 3mm Cold roll Stainless Steel coil Stainless Steel plate for boiler
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| High Light: | steel sheet coil,stainless steel sheet coil |
||
|---|---|---|---|
3mm Cold roll Stainless Steel coil ASTM 409 Stainless Steel plate for boiler
Quick Detail:
1. Commodity: 304 stainless steel plate
2. Brand: JISCO, LISCO, TISCO
3. Grade:304L
4. Certification: ISO,SGS BV
5. Surface: 2B, or as requested
6. Thickness: 0.5mm-3mm
7. Width: 1000mm/1219mm
8. Length: coil or as customer's requirement
9. Standard: ASTM,AISI,SUS,JIS,EN,DIN,BS,GB
Specifications
|
Item |
304 stainless steel sheet |
|
Standard |
ASTM,AISI,SUS,JIS,EN,DIN,BS,GB |
|
Material |
201,202,304,304L,309S,310S,316,316L,316Ti,317L,321,347H, 409,409L,410,420,430 |
|
Finish(Surface) |
NO.1, NO.2D, NO.2B, BA,NO.3, NO.4,NO.240,NO.400,Hairline, NO.8,Brushed |
|
Thickness |
Form 0.5mm-3mm |
|
Width |
1000mm,1219mm,,etc or we can also help cut as you require |
|
Length |
coil or as customer's requirement |
|
Delivery term |
A.7 days if this goods is stock goods. B.30 days if this goods will be produced after order |
|
Advantage |
Good quality with reasonable price |
|
Validity |
Valid time is 3 days for price usually. |
Regular size
| Thickness (mm) | Width (mm) |
| 0.5 | 1000 |
| 0.5 | 1219 |
| 0.6 | 1000 |
| 0.6 | 1219 |
| 0.7 | 1000 |
| 0.7 | 1219 |
| 0.8 | 1000 |
| 0.8 | 1219 |
| 1.0 | 1000 |
| 1.0 | 1219 |
| 1.2 | 1000 |
| 1.2 | 1219 |
| 1.5 | 1000 |
| 1.5 | 1219 |
| 2.0 | 1000 |
| 2.0 | 1219 |
| 2.5 | 1000 |
| 2.5 | 1219 |
| 3.0 | 1000 |
| 3.0 | 1219 |
Application
Stainless steel sheet applies to construction field, ships building industry, petroleum &chemical industries,
war and electricity industries, food processing and medical industry, boiler heat exchanger, machinery and
hardware fields. Stainless steel sheet can be made accordingto the customers requirements. Fast delivery.
Quality assured.Welcome to order more.
Chemical Composition
|
TYPE NO. |
C |
Mn |
P |
S |
Si |
Cr |
Ni |
|
|
% |
% |
% |
% |
% |
% |
% |
|
201 |
≤ 0.15 |
5.5-7.5 |
≤ 0.050 |
≤ 0.03 |
≤ 1.00 |
16.0-18.0 |
3.5-5.5 |
|
202 |
≤ 0.15 |
7.5-10 |
≤ 0.060 |
≤ 0.03 |
≤ 1.00 |
17.0-19.0 |
4.0-6.0 |
|
301 |
≤ 0.15 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
≤ 1.00 |
16.5-18.0 |
6.0-8.0 |
|
302 |
≤ 0.15 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
≤ 1.00 |
17.0-19.0 |
8.0-10.0 |
|
304 |
≤ 0.08 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
≤ 1.00 |
18.0-20.0 |
8.0-10.5 |
|
304L |
≤ 0.03 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
≤ 1.00 |
18.0-20.0 |
8.0-12.0 |
Mechanical Properties
|
TYPE NO. |
Y.S |
T.S. |
ELOG. |
hardness |
||
|
|
N/mm2 |
N/mm2 |
% |
HB |
HRB |
HV |
|
301 |
≥ 205 |
≥ 520 |
≥ 40 |
≤ 207 |
≤ 95 |
≤ 218 |
|
304 |
≥ 205 |
≥ 520 |
≥ 40 |
≤ 187 |
≤ 90 |
≤ 200 |
|
304L |
≥ 175 |
≥ 480 |
≥ 40 |
≤ 187 |
≤ 90 |
≤ 200 |
|
316 |
≥ 205 |
≥ 520 |
≥ 40 |
≤ 187 |
≤ 90 |
≤ 200 |
Standard:
|
ASTM |
USA |
Ameirican Society of Mechanical Engineers |
|
AISI |
USA |
Acronym of American Iron and Steel Institute |
|
JIS |
JP |
Japanese Industrial Standards |
|
DIN |
GER |
Deutsches Institut für Normung e.V. |
|
UNS |
USA |
Unified Numbering System |
