316L cold rolled stainless steel sheet / stainless streel decorative JIS AISI ASTM sheet
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| High Light: | steel sheet coil,stainless steel sheet coil |
||
|---|---|---|---|
316L cold rolled stainless steel sheet JIS AISI ASTM / stainless streel decorative sheet
Quick Detail:
1. Commodity: 316L cold rolled stainless steel sheet
2. Brand: JISCO, LISCO, TISCO
3. Material: 316L
4. Certification: ISO,SGS BV
5. Surface: 2B, NO.1 or as requested
6. Thickness: 0.5mm-6mm
7. Width: 1000mm/1219mm/1500mm
8. Length: coil or as customer's requirement
9. Standard: JIS, AISI, ASTM, etc.
Specifications
|
Item |
316L stainless steel sheet |
|
Description |
Stainless steel sheet,stainless steel plate,cold rolled stainless steel sheet,hot rolled stainless steel sheet, stainless steel checkered sheet,stainless streel decorative sheet. |
|
Standard |
ASTM,AISI,SUS,JIS,EN,DIN,BS,GB |
|
Material |
201,202,304,304L,309S,310S,316,316L,316Ti,317L,321,347H, 409,409L,410,420,430 |
|
Finish(Surface) |
NO.1, NO.2D, NO.2B, BA,NO.3, NO.4,NO.240,NO.400,Hairline, NO.8,Brushed |
|
Exported Area |
USA,UAE,Europe,Asia,Middle East,Africa,South America |
|
Thickness |
Form0.5mm-6mm |
|
Width |
1000mm,1219mm,1500mm,etc or we can also help cut as you require |
|
Length |
2000mm,2440mm(8feet),2500mm,3000mm,3048mm(10feet),5800mm, 6000mm ,8000mm or we can make the length as you require |
|
Application |
Stainless steel sheet applies to construction field, ships building industry, petroleum & chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchanger, machinery and hardware fields. Stainless steel sheet can be made accordingto the customers requirements. Fast delivery. Quality assured.Welcome to order more. |
Surface Finish
| Name | Feature | Specification |
| 2B | Bright | After coldrolling,by heat treatment,picking or other equivalent treatment and lastly by cold rolling to given appropriate luster |
| 2D | Matte | Best choice for deep drawing |
| BA | POlishing,Mirror |
Processed with bright heat treatment after cold rolling |
| NO4 | Discontinuous coarse grain |
Grinding and polishing surface by 150-180# strop grain of abrasive belt |
| Hair Line | Line like hair |
Hair grain grinding by appropriate particle size of material |
| 6K | Mirror,Brighter than BA |
very bright,grinding and polishing surface by 100# strop grain of abrasive belt |
|
Stainless Steel 300 Series |
||||||||||||||
|
Grade |
Chemical Composition |
Mechanical Properties |
||||||||||||
|
|
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Mo |
|
Y.S |
T.S. |
ELOG. |
HRB |
|
|
% |
% |
% |
% |
% |
% |
% |
% |
|
N/mm2 |
N/mm2 |
% |
|
||
|
304 |
≤ 0.08 |
≤ 0.75 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
8~10 |
18~20 |
|
|
≥ 205 |
≥ 520 |
≥ 40 |
≤ 90 |
|
|
301 |
≤ 0.15 |
≤ 1.00 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
6~8 |
16~18 |
|
|
≥ 205 |
≥ 515 |
≥ 40 |
≤ 95 |
|
|
316 |
≤ 0.08 |
≤ 1.00 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
10~14 |
16~18 |
2~3 |
|
≥ 205 |
≥ 515 |
≥ 40 |
≤ 90 |
|
|
316L |
≤ 0.03 |
≤ 1.00 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
12~15 |
16~18 |
2~3 |
|
≥ 170 |
≥ 480 |
≥ 40 |
≤ 95 |
|
|
The specification of type 301, 304, 316, 316L according with ASTM and JIS standard. |
||||||||||||||
advantage:
Our company located in shanghai,near Shanghai port,it is convenient to transport the cargo to the port, so it save the time,and can cut down the delivery time also can save the cost of transportation, the customer can get the benefit.
