Thin Wall 00Cr19Ni10 Brushed 304L Stainless Steel Coils equal SUS JIS EN DIN BS GB
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| High Light: | Cold Rolled Stainless Steel Coils,stainless steel sheet coil |
||
|---|---|---|---|
00Cr19Ni10 Brushed 304L Stainless Steel Coils Thin Wall SUS JIS EN DIN BS GB
Quick Detail:
1. Commodity: 304L stainless steel plate
2. Brand: JISCO, LISCO, TISCO
3. Material:304L
4. Certification: ISO,SGS BV
5. Surface: 2B, NO.1 or as requested
6. Thickness: 0.5mm-6mm
7. Width: 1000mm/1219mm/1500mm
8. Length: coil or as customer's requirement
9. Standard: ASTM,AISI,SUS,JIS,EN,DIN,BS,GB
10.GB:00Cr19Ni10
Specifications
Surface Finish
| Name | Feature | Specification |
| 2B | Bright | After coldrolling,by heat treatment,picking or other equivalent treatment and lastly by cold rolling to given appropriate luster |
| 2D | Matte | Best choice for deep drawing |
| BA | POlishing,Mirror |
Processed with bright heat treatment after cold rolling |
| NO4 | Discontinuous coarse grain |
Grinding and polishing surface by 150-180# strop grain of abrasive belt |
| Hair Line | Line like hair |
Hair grain grinding by appropriate particle size of material |
| 6K | Mirror,Brighter than BA |
very bright,grinding and polishing surface by 100# strop grain of abrasive belt |
Regular size
| Thickness (mm) | Width (mm) | Thickness (mm) | Width (mm) |
| 0.5 | 1000 | 1.2 | 1219 |
| 0.5 | 1219 | 1.5 | 1000 |
| 0.6 | 1000 | 1.5 | 1219 |
| 0.6 | 1219 | 2.0 | 1000 |
| 0.7 | 1000 | 2.0 | 1219 |
| 0.7 | 1219 | 2.5 | 1000 |
| 0.8 | 1000 | 2.5 | 1219 |
| 0.8 | 1219 | 3.0 | 1000 |
| 1.0 | 1000 | 3.0 | 1219 |
| 1.0 | 1219 | 3.0 | 1500 |
| 1.2 | 1000 | 4.0 | 1500 |
| 1.2 | 1219 | 5.0 | 1500 |
| 1.5 | 1000 | 6.0 | 1500 |
Chemical Composition
|
TYPE NO. |
C |
Mn |
P |
S |
Si |
Cr |
Ni |
|
|
% |
% |
% |
% |
% |
% |
% |
|
201 |
≤ 0.15 |
5.5-7.5 |
≤ 0.050 |
≤ 0.03 |
≤ 1.00 |
16.0-18.0 |
3.5-5.5 |
|
202 |
≤ 0.15 |
7.5-10 |
≤ 0.060 |
≤ 0.03 |
≤ 1.00 |
17.0-19.0 |
4.0-6.0 |
|
301 |
≤ 0.15 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
≤ 1.00 |
16.5-18.0 |
6.0-8.0 |
|
302 |
≤ 0.15 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
≤ 1.00 |
17.0-19.0 |
8.0-10.0 |
|
304 |
≤ 0.08 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
≤ 1.00 |
18.0-20.0 |
8.0-10.5 |
|
304L |
≤ 0.03 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
≤ 1.00 |
18.0-20.0 |
8.0-12.0 |
Mechanical Properties
|
TYPE NO. |
Y.S |
T.S. |
ELOG. |
hardness |
||
|
|
N/mm2 |
N/mm2 |
% |
HB |
HRB |
HV |
|
301 |
≥ 205 |
≥ 520 |
≥ 40 |
≤ 207 |
≤ 95 |
≤ 218 |
|
304 |
≥ 205 |
≥ 520 |
≥ 40 |
≤ 187 |
≤ 90 |
≤ 200 |
|
304L |
≥ 175 |
≥ 480 |
≥ 40 |
≤ 187 |
≤ 90 |
≤ 200 |
|
316 |
≥ 205 |
≥ 520 |
≥ 40 |
≤ 187 |
≤ 90 |
≤ 200 |
Application
Stainless steel sheet applies to construction field, ships building industry, petroleum &chemical industries,
war and electricity industries, food processing and medical industry, boiler heat exchanger, machinery and
hardware fields. Stainless steel sheet can be made accordingto the customers requirements. Fast delivery.
Quality assured.Welcome to order more.
Standard:
|
ASTM |
USA |
Ameirican Society of Mechanical Engineers |
|
AISI |
USA |
Acronym of American Iron and Steel Institute |
|
JIS |
JP |
Japanese Industrial Standards |
|
DIN |
GER |
Deutsches Institut für Normung e.V. |
|
UNS |
USA |
Unified Numbering System |
