Casting Steel Ball Float Air Trap For Air Line ，Gas Tank

Casting Steel Ball Float Air Trap For Air Line , Gas Tank


Quick Details:

Standards: ANSI, NPT, BSPT, JIS, GB

Structure: Free Float Air Trap

Pressure:0.01 - 1.6 MPa

Media: Steam, Water

Materials: WCB, Stainless Steel

Application: Suitable for air line

Free Float Air Trap
High Precision Grinding Stainless Steel Float
Water & Oil can be removed from air system easily
80% Back Pressure Rate

Air Trap / Ball Float Air Trap

Model:AJ7N

Features:

• 1. High-precision grinding stainless steel float improves the performance of compression strength, sealing and anti-corrosion.
• 2. The equalizing pipe can prevent air locking and ensure rapid start-up of the steam trap.
• 3. Reliable working and long service life with the only one moving float.
• 4. Water and oil can be discharged continuously with low noise.
• 5. The back pressure rate up to 80%.

Application:
Suitable for air line, secondary cooler, gas tank, compressing air system and all kinds of equipment for air purification system.
