Low Energy Consumption Ball Mill Parts For Fine Powder Grinding

Low Energy Consumption Ball Mill Parts For Fine Powder Grinding
Low Energy Consumption Ball Mill Parts For Fine Powder Grinding

Large Image :  Low Energy Consumption Ball Mill Parts For Fine Powder Grinding Get Best Price

Product Details:
Place of Origin: China
Brand Name: GEAR
Certification: SGS/CITIC Inspection Report
Model Number: ball mill spare parts
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: negotiation
Packaging Details: Seaworthy plywood packaged on stell pallets or as customer's request
Delivery Time: 45 working days after received your payment
Payment Terms: T/T
Supply Ability: 60K Tone per month
Detailed Product Description
Product Name: Ball Mill Spare Parts Application: Ball Mill
Size: 1/2"~64" Resolution: 4000*1500
Dimensions: As Customers’ Requirements Surface Treatment: Anodized/powder Coating /electrophoretic
Style: Forging Steel
High Light:

ball mill spare parts

High quality CITIC firm supplier of ball mill spare parts in Mining Project



ball mill spare parts, ball mill spare parts manufacturer with ISO



ball mill spare parts is an efficient tool for fine powder grinding. Ball mill is often used for grinding silica sand. The ball mill spare parts is used to grind many kinds of mine and other materials, or to select the mine. ball mill spare parts is widely used in building material, chemicalindustry, etc. There are two ways of grinding: the dry way and the wet way. It can be divided into tabular type and flowing type according to different expelling mine. Shanghai Zenith is a famous ball mill spare parts manufacturer.

Low Energy Consumption Ball Mill Parts For Fine Powder Grinding 0

ball mill spare parts working process and ball mill spare parts working priciple



To use the ball mill spare parts, the material to be ground is loaded into the Neoprene barrel that contains grinding media. As the barrel rotates, the material is crushed between the individual pieces of grinding media that mix and crush the product into fine powder over a period of several hours. Obviously, the longer the ball mill runs, the smaller the powder will be. Ultimate particle size depends entirely on how hard the ground material is, and how long the ball mill spare parts runs. Our ball mill have been being used to grind glass, make ceramic glaze, powder various chemicals, and make Black Powder.



ball mill spare parts Features:



1) Easy and safe operation
2) Stable performance
3) Even product size
4) Low energy consumption
5 Low invest, high return



ball mill spare parts specifications:




Model Rotate Speed (r/min) Grinding Media Weight (T) Feeding Size(mm) Discharge Size (mm) Output(t/h) Motor Power (KW) Weight (T)
900×1800 36~38 1.5 ≤20 0.075-0.89 0.65-2 18.5 4.6
900×3000 36 2.7 ≤20 0.075-0.89 1.1-3.5 22 5.6
1200×2400 36 3 ≤25 0.075-0.6 1.5-4.8 30 12
1200×3000 36 3.5 ≤25 0.074-0.4 1.6-5 37 12.8
1200×4500 32.4 5 ≤25 0.074-0.4 1.6-5.8 55 13.8
1500×3000 29.7 7.5 ≤25 0.074-0.4 2-5 75 15.6
1500×4500 27 11 ≤25 0.074-0.4 3-6 110 21
1500×5700 28 12 ≤25 0.074-0.4 3.5-6 130 24.7
1830×3000 25.4 11 ≤25 0.074-0.4 4-10 130 28
1830×4500 25.4 15 ≤25 0.074-0.4 4.5-12 155 32
1830×6400 24.1 21 ≤25 0.074-0.4 6.5-15 210 34
1830×7000 24.1 23 ≤25 0.074-0.4 7.5-17 245 36
2100×3000 23.7 15 ≤25 0.074-0.4 6.5-36 155 34
2100×4500 23.7 24 ≤25 0.074-0.4 8-43 245 42
2100×7000 23.7 26 ≤25 0.074-0.4 8-48 280 50
2200×4500 21.5 27 ≤25 0.074-0.4 9-45 280 48.5
2200×6500 21.7 35 ≤25 0.074-0.4 14-26 380 52.8
2200×7000 21.7 35 ≤25 0.074-0.4 15-28 380 54
2200×7500 21.7 35 ≤25 0.074-0.4 15-30 380 56
2400×3000 21 23 ≤25 0.074-0.4 7-50 245 54
2400×4500 21 30 ≤25 0.074-0.4 8.5-60 320 65
2700×4000 20.7 40 ≤25 0.074-0.4 12-80 400 94
2700×4500 20.7 48 ≤25 0.074-0.4 12-90 430 102
3200×4500 18 65 ≤25 0.074-0.4 According to the process condition 800 137
