6mm - 101.6mm TIG Welding Stainless Steel Tube / Welded Stainless Steel Tubes 1 Inch - 4 Inch

Germanic standards:

DIN17455:General purpose welded circular stainless steel tubes

DIN17457: Welded circular austenitic stainless steel tubes subject to special requirements; technical delivery conditions

European Standard:

EN 10217-7:Welded Steel Tubes for pressure purposes-Part 7 Stainless steel tubes

European Standard

1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438,

1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501

Russia Standard

08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,

10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,

12Х18Н10Т,12Х18Н12Т,12Х18Н9, 17Х18Н9, 08Х22Н6Т,

Commodity Name

Stainless Steel Welding Tube

Standard

DIN17457, EN10217-7

Material Grade

1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438,

1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501

08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,

10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,

12Х18Н10Т,12Х18Н12Т,12Х18Н9, 17Х18Н9, 08Х22Н6Т,

Outer Diameter

6mm-101.6mm

Wall Thickness

0.3mm – 3.5mm

Length

Depends on Customers’ Request

Tolerance

According to Standards

Leakage Test

ET, RT,  UT  Or  Hydraulic Test Or Air Pressure Test Under Water

Main  process

Welding, Annealing, Pickled, Polish, Satin, 2B Mill Finish

Certificate

ISO 9001:2008, Manufacture License Of Pressure Tube

Marking

Brand, Standard, Grade, Size, Length and Heat No. Or Depends On Customer.

Packing

Bundles With Plastic Bags, Wooden Box With Angle Steel Frame Or others

Payment Terms

T/T, L/C at sight

Price Term

EX-Works, CFR, CNF, CIF, FOB ETC

Delivery Time

Generally 15Days – 45Days Or Depends on the quantity and Customers’ Request

Capacity

1000 Tons Per Month

Grade

Chemical Composition(%)

Remark

C≤

Mn≤

P≤

S≤

Si≤

Cr

Ni

Mo

N

Cu

1.4301

0.07

2

0.045

0.015

1

17.0~19.0

8.0~10.50

0~0.1

1.4307

0.03

2

0.045

0.015

1

17.5~19.5

8.0~10.0

0~0.1

1.4401

0.07

2

0.045

0.015

1

16.5~18.5

10.0~13.00

2.0~2.5

0~0.1

1.4404

0.03

2

0.045

0.015

1

16.5~18.5

10.0~13.00

2.0~2.5

0~0.1

1.4541

0.08

2

0.045

0.015

1

17.0~19.0

9.0~12.00

Ti≥5×C,≤0.70

1.4436

0.05

2

0.045

0.015

1

16.5~18.5

10.5~13.0

2.50~3.00

1.4438

0.03

2

0.045

0.015

1

17.5~19.5

13.0~16.0

3.00~4.00
