TP316L Welding 1 Inch Stainless Steel Threaded Pipe , TIG Welded Tubes 0.30mm - 2.5mm WT
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Product Name: | Welding Stainless Steel Threaded Tube | Material Grade: | TP316L |
|---|---|---|---|
| Outer Diameter: | 6.00mm-50.8mm | Wall Thickness: | 0.3mm – 2.5mm |
| Standard: | ASME SA249 / ASTM A249 | Delivery Condition: | Bright Annealing |
| High Light: | threaded stainless steel tubing,threaded stainless steel tube |
||
TP316L Welding Stainless Steel Threaded Tube,Bright Anneal With Size 25mm x 0.7mm / 0.9mm
Quick detail:
·Product Name: Welding Stainless Steel Threaded Tube
·Standard: ASME SA249 / ASTM A249
·Grade: TP316L
·Outer Diameter : 6.00mm-50.8mm
·Wall thickness : 0.30mm-2.5mm
·Length: max.40000mm or Custom
·Surface finish: Bright Annealing
·Manufacture technology: TIG Welded
· Leakage Test:ET, UT, RT Or Hydraulic Test
· Packing:Bundles With Plastic Bags, Wooden Box With Angle Steel Frame Or others
· Price Terms:EX-Works, CNF, CRF, CIF Etc.
· Payment Terms:T/T, L/C at sight
· Delivery Time:Generally 15Days – 45Days Or Depends on the quantity and Customers’ Request
· Capacity:1000 Tons Per Month
Description:
Standards:
|
SA249 Standard Specification For Welded Austenitic Steel Boiler,Superheater, Heat-Exchanger And Condenser Tubes. |
||
|
Item |
Contents |
Requirements |
|
1 |
Chemical Composition |
Acc.to SA249 and SA480 |
|
2 |
Welding method |
TIG Welding |
|
3 |
Materail |
TP304, TP304L, TP304H, TP310S, TP316, TP316L, TP316TI, TP316H, TP317L, TP321 |
|
4 |
Straightness |
0.8mm/900mm |
|
5 |
Tolerance |
OD acc.to A1016/A1016M,WT +/-10% |
|
6 |
Heat Treatment |
Bright Annealing Temperature 1040℃ |
|
7 |
Mechanical Property |
Mechanical Property:Enlongation 45%-65% Expansion Test:Acc.To ASTM A249 & ASTM A1016 Flange Test: Acc.To ASTM A249 & ASTM A1016 Flattening Test: Acc.To ASTM A249 & ASTM A1016 Hardness:HRB 75-90 |
Material:
|
Grade |
Chemical Composition(%) |
Remark |
|||||||||
|
C≤ |
Mn≤ |
P≤ |
S≤ |
Si≤ |
Cr |
Ni |
Mo |
N |
Cu |
||
|
316 |
0.08 |
2.00 |
0.045 |
0.030 |
0.75 |
16.0~18.0 |
10.0~14.0 |
2.0~3.0 |
0~0.1 |
|
|
|
316L |
0.030 |
2.00 |
0.045 |
0.030 |
0.75 |
16.0~18.0 |
10.0~14.0 |
2.0~3.0 |
0~0.1 |
|
|
Applications:
|
1. Pipes for Liquid Delivery. |
|||
|
2. Tubes for Power Industry(Thermal Power and Nuclear Power Staition) and Petrochemical Industry:Boiler, Heat-sink, Condenser and Heat-exchanger tubes |
|||
|
3. Tubes for Automotive Industry:Oil tube and Exaust System Tubes. |
|||
|
4. Tubes for Medicine and Food Industry. |
|||
|
5. Tubes for Mechanical and Construction. |
|||
Competitive Advantage:
●Supply Best Prices Based On Good Quality And Timely Delivery.
●We Have Advanced NDT Equipments For The Tests Such As Eddy Current Test, Hydraulic Test And So On.And the Pipes Are 100% Inspected of Leakage Test.
●Wooden Case Package Which Is Strong And Suitable For Sea Transport And Which Is Our Main Method To Protect The Tubes.Also We Will Depends On The Sizes Of The Tubes To Select More Ecomony Packing Method By Bundle.
