10mm ERM Mild Steel Tubing Phosphate Coating / Spiral Welded Steel Pipe

Large Image : 10mm ERM Mild Steel Tubing Phosphate Coating / Spiral Welded Steel Pipe Get Best Price

Product Details:

Place of Origin:	China
Brand Name:	JZ
Certification:	ISO 9001:2008, CE
Model Number:	ASTM A519

Payment & Shipping Terms:

Minimum Order Quantity:	1 tons
Price:	USD 800-2000 per ton
Packaging Details:	Seaworthy packing or customers’ detailed request
Delivery Time:	Within 30 days after order confirmed
Payment Terms:	L/C or TT
Supply Ability:	5,000tons per month.

Contact Now

Detailed Product Description

High Light:

Anti corrosion steel pipe

mild steel exhaust tubing

10mm ERM Mild Steel Tubing Phosphate Coating / Spiral Welded Steel Pipe

Detailed Product Description

Features:	Thin Wall	Application:	Machinery, Automobiles, Bicycles, Furniture, Appliances, Chemical
Delivery Condition:	Annealed, Normalized, Tempered, BK, BKS, BKW, NBK, GBK	Grade:	SCr420TK, SCM415TK, SCM418TK
Material:	Alloy Steel	Product Name:	Mild Steel Tubing
Section Shape:	Round	Standard:	JIS G3441
Surface Treatment:	Oil dip, Varnish, Passivation, Phosphating, Shot Blasting	Technique:	Seamless

Quick Detail:

Standards: JIS G3441
Grade: SCr420TK SCM415TK SCM418TK SCM420TK SCM430TK SCM435TK SCM440TK
Size (mm):
Out Dimensions: 6mm ~ 350mm
Wall Thickness: 0.8mm ~ 35mm
Length: Fixed (6m,9m,12,24m) or normal length(5-12m)

Description:

Standards: JIS G3441
Grade: SCr420TK SCM415TK SCM418TK SCM420TK SCM430TK SCM435TK SCM440TK
Size (mm):
Outer Dimensions: 6mm ~ 350mm
Wall Thickness: 0.8mm ~ 35mm
Length: max 24000mm
Application: Tubes used for machinery, automobiles, bicycles, furniture, appliances and other machine parts.
Packing: Beveled / black painting/ plastic caps/ in bundles/ steel strips/ wooden protection
Inspection and Test: Chemical Composition Inspection, Mechanical Properties Test(Tensile Strength, Yield Strength,Elongation, Flaring, Flattening, Bending, Hardness, Impact Test),Surface and Dimension Test,Nodestructive Test, Hydrostatic Test.
Surface treatment:Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting
Mark: As requested.
Delivery Condition: Annealed, Normalized, Normalized and Tempered

Si
Size range of JIS G3441 Alloy Steel Tubes:
Tolerance on Outside Diameter in JIS G3441

O.D.(mm)	Tolerance(%)
<13 td>	0.25
<13-25	0.40
<25-40	0.60
<40-65	0.80
<65-90	1.00
<90-140	1.20
<140	By agreement

Tolerance on Wall Thickness in JIS G3441

W.T.(mm)	Tolerance
< td>	-0.5,+0.6
<4	-12.5%, +15%

How to Test JIS G3441 Alloy Steel Tubes:

Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength, Yield strength, Elongation)
Technical Properties (Flattening Test, Flaring Test, Bending Test, Hardness Test, Blow Test, Impact Test etc)
Exterior Size Inspection.
Mill Test Certificate:EN 10204/3.1B
Delivery Condition:BKS, NBK,BK ,BKW, GBK(+A), NBK(+N), BK(+C)

JIS G3441 Alloy Steel Tubes Chemical composition Limits(%):

Steel grade	Steel grade(old)	C	Si	Mn	P	S	Cr	Mo
SCr420TK		0.18~0.23	0.15~0.35	0.60~0.85	<0 td>	<0 td>	0.90~1.20	0.15~0.30
SCM415TK		0.13~0.18	0.15~0.35	0.60~0.85	<0 td>	<0 td>	0.90~1.20	0.15~0.30
SCM418TK		0.16~0.21	0.15~0.35	0.60~0.85	<0 td>	<0 td>	0.90~1.20	0.15~0.30
SCM420TK		0.18~0.23	0.15~0.35	0.60~0.85	<0 td>	<0 td>	0.90~1.20	0.15~0.30
SCM430TK	As STKS1	0.33~0.38	0.15~0.35	0.60~0.85	<0 td>	<0 td>	0.90~1.20	0.15~0.30
SCM435TK	As STKS3	0.33~0.38	0.15~0.35	0.60~0.85	<0 td>	<0 td>	0.90~1.20	0.15~0.30
SCM440TK		0.38~0.43	0.15~0.35	0.60~0.85	<0 td>	<0 td>	0.90~1.20	0.15~0.30

Applications:

JIS G3441 Alloy steel tubes for machine purposes
