Electro-Galvanised Iron Wire For Weaving Sqaure mesh and Hexagonal wire netting
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
Electro-Galvanized iron wire
Quick Detail:
|
Name |
Products Nickname |
|
|
Electro- Galvanized iron wire |
Galvanized steel wire, Galvanized iron wire, G.I Wire, Binding wire |
|
|
Material |
Low carbon steel Q195, equal to SAE1006 & SAE1008 |
|
|
Tensile Strength |
380-550N/mm2 |
|
|
Zinc-coating |
8-10g/m2
|
|
Description:
We use quality low carbon steel wire in producing of Eelctro-galvanized wire, It is thin wire from 0.45mm to 1.0mm. The Coil weight Can be with normal packing 10kg per coil to 50kg per coil, or pack it with spool. High quality and inexpensive products get goodwill in iron wire business line.
Applications:
Electro-galvanized wire is extremely flexible and soft, extensively used in weaving square mesh, hexagonal wire netting, chicken mesh, handicrafts, packaging of products and other daily uses.
Specifications:
|
Electro-Galvanized iron Wire |
|||
|
Wire Gauge |
SWG in mm |
BWG in mm |
In Metric System mm |
|
19# |
1.02 |
1.06 |
1.0 |
|
20# |
0.91 |
0.91 |
0.91 |
|
21# |
0.81 |
0.81 |
0.81 |
|
22# |
0.71 |
0.71 |
0.71 |
|
23# |
0.61 |
0.63 |
0.63 |
|
24# |
0.56 |
0.56 |
0.56 |
|
25# |
0.50 |
0.50 |
0.50 |
|
26# |
0.46 |
0.46 |
0.46 |
If you need exactly wire diameter with Milimeter, it can be customized.
