Thin Wall 304 Stainless Steel Coil Hot Rolled Stainless Steel Plate Brushed Finish
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Material: | 304 | Standard: | ASTM,AISI,SUS,JIS,EN,DIN,BS,GB |
|---|---|---|---|
| Surface: | 2B, NO.1 Or As Requested | Thickness: | 3.0mm-16mm |
| High Light: | polished stainless steel plate,stainless steel metal plate |
||
Thin Wall 304 Stainless Steel Coil Hot Rolled Stainless Steel Plate Brushed Finish
Quick Detail:
1. Commodity: 304 Hot Rolled Stainless Steel Coil
2. Brand: JISCO, LISCO, TISCO
3. Material:304
4. Certification: ISO,SGS BV
5. Surface: 2B, NO.1 or as requested
6. Thickness:3.0mm-16mm
7. Width: 1500mm
8. Length: coil or as customer's requirement
9. Standard: ASTM,AISI,SUS,JIS,EN,DIN,BS,GB
Specifications
Surface Finish
| Name | Feature | Specification |
| 2B | Bright | After coldrolling,by heat treatment,picking or other equivalent treatment and lastly by cold rolling to given appropriate luster |
| 2D | Matte | Best choice for deep drawing |
| BA | POlishing,Mirror |
Processed with bright heat treatment after cold rolling |
| NO4 | Discontinuous coarse grain |
Grinding and polishing surface by 150-180# strop grain of abrasive belt |
| Hair Line | Line like hair |
Hair grain grinding by appropriate particle size of material |
| 6K | Mirror,Brighter than BA |
very bright,grinding and polishing surface by 100# strop grain of abrasive belt |
|
Item |
304 Hot Rolled Stainless Steel Coil |
|
Standard |
ASTM,AISI,SUS,JIS,EN,DIN,BS,GB |
|
Finish(Surface) |
NO.1, NO.2D, NO.2B, BA,NO.3, NO.4,NO.240,NO.400,Hairline, NO.8,Brushed |
|
Exported Area |
USA,UAE,Europe,Asia,Middle East,Africa,South America |
|
Thickness |
Form 3.0mm-16mm |
|
Width |
1500mm,etc or we can also help cut as you require |
|
Length |
6000mm-8000mm or we can make the length as you require |
Application
Stainless steel sheet applies to construction field, ships building industry, petroleum &chemical industries,
war and electricity industries, food processing and medical industry, boiler heat exchanger, machinery and
hardware fields. Stainless steel sheet can be made accordingto the customers requirements. Fast delivery.
Quality assured.Welcome to order more.
Chemical Composition
|
TYPE NO. |
C |
Mn |
P |
S |
Si |
Cr |
Ni |
|
|
% |
% |
% |
% |
% |
% |
% |
|
201 |
≤ 0.15 |
5.5-7.5 |
≤ 0.050 |
≤ 0.03 |
≤ 1.00 |
16.0-18.0 |
3.5-5.5 |
|
202 |
≤ 0.15 |
7.5-10 |
≤ 0.060 |
≤ 0.03 |
≤ 1.00 |
17.0-19.0 |
4.0-6.0 |
|
301 |
≤ 0.15 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
≤ 1.00 |
16.5-18.0 |
6.0-8.0 |
|
302 |
≤ 0.15 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
≤ 1.00 |
17.0-19.0 |
8.0-10.0 |
|
304 |
≤ 0.08 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
≤ 1.00 |
18.0-20.0 |
8.0-10.5 |
|
304L |
≤ 0.03 |
≤ 2 |
≤ 0.045 |
≤ 0.03 |
≤ 1.00 |
18.0-20.0 |
8.0-12.0 |
Mechanical Properties
|
TYPE NO. |
Y.S |
T.S. |
ELOG. |
hardness |
||
|
|
N/mm2 |
N/mm2 |
% |
HB |
HRB |
HV |
|
301 |
≥ 205 |
≥ 520 |
≥ 40 |
≤ 207 |
≤ 95 |
≤ 218 |
|
304 |
≥ 205 |
≥ 520 |
≥ 40 |
≤ 187 |
≤ 90 |
≤ 200 |
|
304L |
≥ 175 |
≥ 480 |
≥ 40 |
≤ 187 |
≤ 90 |
≤ 200 |
|
316 |
≥ 205 |
≥ 520 |
≥ 40 |
≤ 187 |
≤ 90 |
≤ 200 |
Standard:
|
ASTM |
USA |
Ameirican Society of Mechanical Engineers |
|
AISI |
USA |
Acronym of American Iron and Steel Institute |
|
JIS |
JP |
Japanese Industrial Standards |
|
DIN |
GER |
Deutsches Institut für Normung e.V. |
|
UNS |
USA |
Unified Numbering System |
